Construction Products

The EU Construction Products Regulation (CPR) is the basis of construction products regulations used in all member states including the UK. This Regulation requires construction products to be classified using a set of reaction to fire test methods. These products include all wall lining, flooring, roofing and other fixed products such as linear pipe thermal insulation products and electric cables.

The CPR required all member states to classify these products using the test methods and systems described in EN 13501. These test methods, and in some cases the classification system, are now being used extensively beyond the European Union — both by countries wanting to establish or upgrade their own regulations without spending extensive research and development budgets, and by producers wanting to export products to Europe. intersciencefire engineers have worked with CEN in the development of these test methods.

Fire tests for construction products

5 matching test methods. Each card opens the full test method page.

EN 13823

Single Burning Item Test — SBI

Reaction-to-fire testing for construction products exposed to thermal attack from a single burning item.

Measures:
Heat release (THR, FIGRA) · Smoke production (SMOGRA) · Lateral flame spread · Flaming droplets/particles
Markets:
Construction Products
Related classification:
EN 13501-1
View test method

EN ISO 11925-2

Ignitability — Single Flame Source Test

Determines the ignitability of building products in the vertical orientation when subjected to impingement of a standard small flame.

Measures:
Ignitability · Flame spread (Fs) · Flaming droplets/particles
Markets:
Construction Products · Railway · Marine
Related classification:
EN 13501-1 · EN 45545-2 · IMO FTP Code
View test method

EN ISO 1182

Non-Combustibility Test

Determines the non-combustibility performance of homogeneous products and substantial components of non-homogeneous building products.

Measures:
Temperature rise (ΔT) · Mass loss (Δm) · Sustained flaming (tf)
Markets:
Construction Products · Marine
Related classification:
EN 13501-1 · IMO FTP Code
View test method

EN ISO 1716

Heat of Combustion — Bomb Calorimeter

Determines the potential maximum total heat release of a product when completely burning, regardless of its end use.

Measures:
Gross heat of combustion (PCS)
Markets:
Construction Products · Electric Cables
Related classification:
EN 13501-1 · EN 13501-6
View test method

EN ISO 9239-1

Flooring Radiant Panel Test — FRP

Measures the critical radiant flux of horizontally mounted floor covering systems exposed to a flaming ignition source in a graded radiant heat environment.

Measures:
Critical radiant flux · Smoke production
Markets:
Construction Products · Railway
Related classification:
EN 13501-1 · EN 45545-2
View test method

Need help choosing the right construction products test?

Tell us what you make and where it will be used. We will come back with the exact tests and the classification route to plan for.
